SLS08

SLS-08 SERIES

Using single or double RXD-08 directional MR16 bullet fixtures, the SLS-08 is ideal for lighting building mounted signs from either uplight or downlight positions. A large selection of 12v lamp options allow for precise lighting and beam control

SPECIFICATIONS

Brass: Machined brass cylinder with threaded cap & cast brass adjustable swivel; die cast canopy & extruded brass extension pole

Max Wattage: 35w

Lens: Flat or stepped flat glass

Lamp Options: LED options, see specification sheet

Socket 12v: High temperature ceramic GU5.3 bi-pin with 250°C

silicone lead wires

Wiring 12v: Black 18/2 SPT-1W 8” from base of fixture

Power Supply 12v: Not included. Requires remote 12v transformer or HW-12-75 integrated 12v hardwire transformer. Integrated LED driver HW-12-8700-LED (120v-230v, 8w 700mA) also available.

Finish: Optional finishes available; see specification sheet for details & colors. Custom colors available.

Note: LED must be powered by magnetic transformer or LED driver
